Description
The Jazzy Evo 614 HD Powerchair is built for strength and performance, combining heavy-duty capacity with a maneuverable mid-wheel drive platform. With a weight capacity of 204 kg and a turning radius of 56 cm, it handles both indoor and outdoor environments with agility.
It features Active-Trac┬о ATX suspension (front & rear independent) to smooth out rough terrain, plus a 60A Dynamic LiNX controller and memory foam high-back swivel seat for ride comfort.
Whether navigating indoors or going out into the community, this chair offers a strong balance of maneuverability, durability, and comfort.
Product Highlights
- Heavy-duty capacity: 450 lbs (тЙИ 204 kg)
- 22″ (тЙИ 56 cm) turning radius
- Up to 4.88 mph (тЙИ 7.85 km/h) top speed
- Full independent front & rear Active-Trac┬о ATX suspension
- 13.75″ perforated drive wheels for better traction
- Memory foam high-back swivel seating, depth adjustable, limited recline
- 60A Dynamic LiNX controller with speed dial
- Removable matte-finish shrouds in multiple colours
- Access to controller and batteries without standing
Product Specifications
| Specification | Details |
| Weight Capacity | 450 lbs (тЙИ 204 kg) |
| Turning Radius | 22″ (тЙИ 56 cm) |
| Overall Width | 25.4″ (тЙИ 64.5 cm) |
| Overall Length | 40.5″ (тЙИ 103 cm) |
| Top Speed | Up to 4.88 mph (тЙИ 7.85 km/h) |
| Ground Clearance | 3″ (тЙИ 7.6 cm) |
| Front & Rear Casters | 6″ solid |
| Drive Wheels | 13.75″ perforated |
| Drive Train | Two-motor, inline, HD motors |
| Braking System | Regenerative + electro-mechanical |
| Suspension | Active-Trac┬о ATX, front & rear independent |
| Seat Sizes Available | Up to 24″ W ├Ч 24″ D |
| Seat-to-Floor Range | 22″ тАУ 24″ (тЙИ 56 cm тАУ 61 cm) |
| Per Charge Range | Up to 13 miles @ 450 lbs; Up to 21.5 miles @ 200 lbs |
| Electronics | 60A Dynamic LiNX |
| Battery Type | (2) NF-22 batteries |
| Base Weight (heaviest piece) | 125.7 lbs (тЙИ 57 kg) |
| Seat Weight | 57.8 lbs (тЙИ 26.2 kg) |
| Battery Weight (each) | 36 lbs (тЙИ 16.3 kg) |
| Total Weight (base + seat + batteries) | 255.5 lbs (тЙИ 116 kg) |
Applications / Ideal For
- Users needing a┬аhigh weight capacity (heavy-duty)┬аpowerchair
- People who navigate both┬аindoor tight spaces and outdoor terrain
- Those wanting┬аride comfort and stability over uneven surfaces
- Situations where┬аswivel seating, independent suspension, and large drive wheels┬аare advantageous
Optional Accessories
- Swing-away joystick mount
- Oxygen tank holder
- Rear basket
- Cane / crutch holder
- Cup holder
- Weather-resistant cover
- Elevated leg rests
- Swing-away leg rests
- Heel loops
- Various lap belt options
The Jazzy Evo 614 HD is a robust, versatile heavy-duty powerchair built to perform both indoors and outdoors. With advanced suspension, strong capacity, and features designed for comfort and adaptability, itтАЩs an excellent choice for users seeking strength without compromising on maneuverability or ride quality.
